CET 20HP High Volume Portable Fire Pump Honda Engine
CET Fire Pumps Logo

20HP High Volume Portable Fire Pump

SKU: PFP-20HPHND-2D

The CET 20HP High Volume Portable Fire Pump is the ideal tool to fill your fire truck, supply your pump truck, or carry water over a long distance. Engine and pump are mounted on a protective frame made of steel with shock absorbers and folding handles.

Honda Engine
Features

  • C.E.T. single stage centrifugal pump
  • Pump body made from high resistance aluminum alloy
  • Bronze impeller
  • Mechanical shaft seal
  • Exhaust priming system, guaranteed up to 20ā€™ (6 meter) lift
  • Two 2 1ā„2ā€ (65 mm) delivery outlet with 1/4-turn ball valve
  • One 4ā€ (100 mm) suction inlet
  • Dimensions: Length: 21 1ā„4ā€ (540 mm). Width: 26 1ā„2ā€ (673 mm); Height: 24ā€ (610 mm)
  • Weight: 198 lbs (90 kg)

Technical Specs

  • GX630 Honda air cooled engine or a CH640 Kohler air cooled engine
  • V-Twin cylinder, 4-stroke gasoline engine
  • Electric start
  • 6 gallon (22 l) detachable fuel tank

Extended Information

Honda Engine Performance

  • MAX FLOW : 630 GPM
  • MAX PRESSURE : 105 PSI
  • 410 GPM @ 25 PSI
  • 300 GPM @ 50 PSI
  • 100 GPM @ 100 PSI
Honda Engine PerformanceKohler Engine Performance
  • 490 GPM @ 10 PSI
  • 430 GPM @ 25 PSI
  • 260 GPM @ 75 PSI
  • 165 GPM @ 100 PSI
  • 90 GPM @ 125 PSI
Kohler Engine Performance
